Maximum
Insulation
O.D.
metric(inch/mm) |
CABLE TYPE |
Q'TY
BOX |
PIC-unfilled
metric(mm) A.W.G. |
PIC-filled
metric(mm) A.W.G. |
Pulp or Paper
metric(mm) A.W.G. |
1.52 0.060 |
.7-.4 22-26 |
.7-.4 22-26 |
.7-.4 22-26 |
|
1.27 0.050 |
.7-.4 22-26 |
.5-.4 24-26
Note: Can be used on
22 AWG(.65mm) Foam
Insulated Cable |
.7-.4 22-26 |
|
1.67 0.066 |
.9-.4 19-26 |
.7-.4 22-26
Note: Can be used on
19 AWG(.9mm) Foam
Insulated Cable |
.9-.4 16-26 |
|
