Product List (Total: 19 records) |
Data Source Page NO.: P.383-5,
WIRE
RANGE
A.W.G.
mm2 |
ITEM NO. |
STUD SIZE |
DIMENSION inch(mm) |
CRIMPING
TOOL |
Q'TY
BOX |
BRAZED
SEAM |
BUTTED
SEAM |
d2 |
W
|
F
|
L
|
E
|
D
|
d1
|
T
|
22-16
A.W.G.
0.5-1.5
mm2
|
|
|
#4 |
.126 3.2 |
.217
5.5
|
.197
5
|
.693
17.6
|
.433
11
|
0.157
4.000
|
.067
1.7
|
.03
.75
|
K.S.MODEL
KM-70PS
WITH DIE INDEX
NO.:PSF011 |
2500 |
|
|
#6 |
.146 3.7 |
.26
6.6
|
.248
6.3
|
.768
19.5
|
.433
11
|
0.157
4.000
|
.067
1.7
|
.03
.75
|
2500 |
|
|
#8 |
.169 4.3 |
.315
8
|
.276
7
|
.819
20.8
|
.433
11
|
0.157
4.000
|
.067
1.7
|
.03
.75
|
2500 |
|
|
#10 |
.209 5.3 |
.315
8
|
.276
7
|
.803
20.4
|
.433
11
|
0.157
4.000
|
.067
1.7
|
.03
.75
|
2500 |
|
|
1/4 |
.252 6.4 |
.457
11.6
|
.433
11
|
1.035
26.3
|
.433
11
|
0.157
4.000
|
.067
1.7
|
.03
.75
|
2500 |
|
|
5/16 |
.331 8.4 |
.457
11.6
|
.433
11
|
1
25.4
|
.433
11
|
0.157
4.000
|
.067
1.7
|
.03
.75
|
2500 |
|
|
3/8 |
.413 10.5 |
.591
15
|
.539
13.7
|
1.122
28.5
|
.433
11
|
0.157
4.000
|
.067
1.7
|
.03
.75
|
2500 |
16-14
A.W.G.
1.5-2.5
mm2
|
|
|
#4 |
.126 3.2 |
.26
6.6
|
.185
4.7
|
.709
18
|
.433
11
|
0.177
4.500
|
.091
2.3
|
.031
.8
|
K.S.MODEL
KM-70PS
WITH DIE INDEX
NO.:PSF012 |
2500 |
|
|
#6 |
.146 3.7 |
.26
6.6
|
.248
6.3
|
.768
19.5
|
.433
11
|
0.177
4.500
|
.091
2.3
|
.031
.8
|
2500 |
|
|
#8 |
.169 4.3 |
.335
8.5
|
.307
7.8
|
.862
21.9
|
.433
11
|
0.177
4.500
|
.091
2.3
|
.031
.8
|
2500 |
|
|
#10 |
.209 5.3 |
.374
9.5
|
.287
7.3
|
.85
21.6
|
.433
11
|
0.177
4.500
|
.091
2.3
|
.031
.8
|
2500 |
|
|
1/4 |
.252 6.4 |
.472
12
|
.433
11
|
1.043
26.5
|
.433
11
|
0.177
4.500
|
.091
2.3
|
.031
.8
|
2500 |
|
|
5/16 |
.331 8.4 |
.472
12
|
.433
11
|
1.012
25.7
|
.433
11
|
0.177
4.500
|
.091
2.3
|
.031
.8
|
2500 |
|
|
3/8 |
.413 10.5 |
.591
15
|
.539
13.7
|
1.122
28.5
|
.433
11
|
0.177
4.500
|
.091
2.3
|
.031
.8
|
2500 |
12-10
A.W.G.
4-6
mm2
|
|
|
#8 |
.169 4.3 |
.283
7.2
|
.358
9.1
|
1.02
25.9
|
.512
13
|
0.252
6.400
|
.134
3.4
|
.039
1
|
K.S.MODEL
KM-70PS
WITH DIE INDEX
NO.:PSF015 |
2000 |
|
|
#10 |
.209 5.3 |
.374
9.5
|
.358
9.1
|
1.008
25.6
|
.512
13
|
0.252
6.400
|
.134
3.4
|
.039
1
|
2000 |
|
|
1/4 |
.252 6.4 |
.472
12
|
.413
10.5
|
1.11
28.2
|
.512
13
|
0.252
6.400
|
.134
3.4
|
.039
1
|
2000 |
|
|
5/16 |
.331 8.4 |
.591
15
|
.531
13.5
|
1.276
32.4
|
.512
13
|
0.252
6.400
|
.134
3.4
|
.039
1
|
2000 |
|
|
3/8 |
.413 10.5 |
.591
15
|
.531
13.5
|
1.24
31.5
|
.512
13
|
0.252
6.400
|
.134
3.4
|
.039
1
|
2000 |
|
|
|
|
