產(chǎn)品介紹

312 Series


  312 Series    312 SERIES


SPECIFICATIONS
Material Connector --
Male Terninal --
Female Terninal BRASS
Operating Temperature Range -40°C ~ +120°C
Voltage Drop 5mV/A
Isolation Resistance -
Dielectric Resistance -
Applicable Wire Size 0.85mm2 ~ 6.0mm2 (18AWG~10AWG)
Maximum Electric Current 40A

TERMINAL
ITEM NO. WIRE RANGE MATERIAL PLATINGS Q'TY REEL APPLICATOR DIES
A.W.G. mm2
1200A0281 18-16 0.85-1.25 Brass None 1000 CDM-97010-M CDT-97010-M
1200A0283 12-10 3.0-5.0 Brass None 1000 CDM-97010-L CDT-97010-L
1201A0281 18-16 0.85-1.25 Brass Pre-Tin 1000 CDM-97010-M CDT-97010-M
1201A0283 12-10 3.0-5.0 Brass Pre-Tin 1000 CDM-97010-L CDT-97010-L

ITEM NO. WIRE RANGE MATERIAL PLATINGS Q'TY REEL APPLICATOR DIES
A.W.G. mm2
FJ312-01B28 14-10 2.0-6.0 Brass Tin 4000 CDM-96020-J CDT-96020-J
FJ312-01B98 14-10 2.0-6.0 Brass None 3000 CDM-96020-J CDT-96020-J


Barrel Types


Terminals Type


Wire Range


Stud Size
