  Other    SQUARE TERMINALS


SPECIFICATIONS
Material Connector -
Female Terninal BRASS
Operating Temperature Range -40°C ~ +120°C
Voltage Drop 5mV/A
Isolation Resistance -
Dielectric Resistance -
Applicable Wire Size 0.3mm2 ~1.4mm2 (22AWG~16AWG)
Maximum Electric Current 18A

TERMINAL
ITEM NO. WIRE RANGE MATERIAL PLATINGS Q'TY REEL APPLICATOR DIES
A.W.G. mm2
NM000-01B9 22-18 0.3-0.8 Brass None 10000 CDM-98020-M CDT-98020-M

ITEM NO. WIRE RANGE MATERIAL PLATINGS Q'TY REEL APPLICATOR DIES
A.W.G. mm2
SM040-01B2 22-16 0.3-1.4 Brass Tin 5000 CDM-93044-M CDT-93044-M
SM040-01B9 22-16 0.3-1.4 Brass None 5000 CDM-93044-M CDT-93044-M
SM040-01BT 22-16 0.3-1.4 Brass Pre-Tin 5000 CDM-93044-M CDT-93044-M
UL/CUL ALL LISTED

ITEM NO. WIRE RANGE MATERIAL PLATINGS Q'TY REEL APPLICATOR DIES
A.W.G. mm2
LM000-01B9 18-16 0.8-1.4 Brass None 4500 CDM-98021-M CDT-98021-M

ITEM NO. WIRE RANGE MATERIAL PLATINGS Q'TY REEL APPLICATOR DIES
A.W.G. mm2
LM000-04K9 18-16 0.85-1.25 Brass None 5000 CDM-9802-M CDT-9802-M


Barrel Types


Terminals Type


Wire Range


Stud Size
